T-Echo
T-Echo
Choose the right firmware version for your needs
Couldn't load pickup availability
About Shipping
About Shipping
Methods & Delivery Time
- Standard Express: 25-30 Days
- YunTu Express : 10-20 Days
(Company name can't be used consignee) - DHL: 10-17 Days
- FedEx: 10-17 Days
Please note that all delivery times are estimated for reference only.
Check More Info: Shipping Policy
About Tax
About Tax
We only charge you for the cost of the product and shipping, no taxes are included.
Specification
| MCU | NRF52840 |
| FLASH | 2MB |
| RAM | 2MB |
| Bus Interfaces | UART, SPI, TWI, PDM, 12S, QSPI |
| Wireless Connectivity |
Bluetooth 5, Thread, Bluetooth Mesh, ANT, 802.15.4, Zigbee With/Without BME280 temperature pressure sensor |
| SX1262 LoRa Transceiver | Long Range, Low Power Global frequency coverage 433, 868, 915Mhz |
| Enclosure material | ABS |
| Version | Normal version / BME280 version |
| Battry Capacity | 850mAh |
1.54-inch SPI E-Paper Display
| Grey level | 2 |
| Resolution | 200x200 |
| Full refresh time | 2S |
L76K Multi-System Positioning GNSS module
| Support System | GPS, GLONASS, BeiDou, QZSS |
| Support Function |
LNA, SAW Filter, AGNSS, 1PPS |
Tech Support
|
ℹ️Firmware 1. LILYGO 2. SoftRF 3. Meshtastic Check out GitHub repository for sample code and more detailed information about this board. 🧑💻LILYGO GitHub Community |
Application scenarios:
- DIY creation - LoRa networking - GPS positioning - IOT terminal control - Stem education product
What's In The Box
