T-Deck Plus

T-Deck Plus

Choose the right firmware version for your needs, MIC certified

17 total reviews

Regular price $70.99
Regular price Sale price $70.99
Sale Sold out
Firmware
Frequency
Color

Methods & Delivery Time

  1. Standard Express: 25-30 Days
  2. YunTu Express : 10-20 Days
    (Company name can't be used consignee)
  3. DHL: 10-17 Days
  4. FedEx: 10-17 Days

Please note that all delivery times are estimated for reference only.

Check More Info: Shipping Policy

For countries other than USA, we only charge product cost + shipping cost, no tax.

Orders from US customers are adjusted according to different shipping channels:

1. For Standard Express Order: We charge【product cost + shipping cost + part of tax】this rate is only applicable to shipment from China warehouse.
(Since the tax is charged according to the declared amount, we have filtered the most suitable solution, and it is most likely that this shipping way does not need you to deal with the customs duty, but it is not absolute)

2. For DHL Order: We charge【product cost + shipping cost】no any tax, tax need you to pay attention to the local policy changes, when the parcel arrives at the US customs, deal with the tax matters by yourself.

----------

The above content is only for charging reference on lilygo.cc website, the specific tax situation still depends on the local country's policy requirements, once the parcel is sent out, you need to keep an eye on its status, and to assist in handling it as needed when it arrives at the local customs, we will also follow up during the process, if you have any

Upgraded based on T-Deck, mainly added GPS module, and Built-in 2000 mah battery

【Keyboard letter styles are sent randomly】

Specifications

MCU ESP32-S3FN16R8 Dual-core LX7 microprocessor
Wireless Connectivity 2.4 GHz Wi-Fi & Bluetooth 5 (LE)
Development Arduino, PlatformlO-IDE, Micropython
Flash 16MB
PSRAM 8MB
Battery ADC PIN IO04
Onboard functions  GPS,TF Card,Microphone,Speaker

 2.8 inch ST7789 SPI Interface IPS LCD:

Resolution: 320 x 240 Full viewing angle

 SX1262 LoRa Transceiver
Transmit power +22dBm
Frequency Optional  433/868/915Mhz

--- LILYGO GitHub Support ---



ℹ️Product Information
Check out our GitHub repository for sample code and more detailed information about this board.

 🧑‍💻Technical support
Visit our GitHub community, post a description of the problem and our engineers will help you directly.


An external antenna connector is reserved on the case, you can connect it by opening the small hole in the case.


Pin Diagram

More

What's In The Box

433Mhz

View full details
  • Who can use

    It's easier to master these development boards with a basic programming knowledge [engineers/ students/ makers, etc..]

  • Accelerated processing

    International orders please make sure your address is in English
    For Hong Kong, Macau and Taiwan orders, please note your personal ID.

  • Got a question

    Click on the bubble in the bottom right corner where some frequently asked questions are answered, or just drop us a line.

Customer Reviews

Based on 17 reviews
59%
(10)
12%
(2)
12%
(2)
0%
(0)
18%
(3)
D
Daniel Polukhin
Love this device

Works well with Meshtastic and MeshCore! Great battery life

G
Gianluca Passarella

good grande potenziale.

M
Michal Adamski

works as expected

J
James
Amaizng device so much potential

Great device well put together works well with multiple firmware i have tried with with especially MUI (fancy ui) for Meshtastic

K
Kurt Baumann
Perfekt use with MeshCom 4.0 firmware

Have a Look at our project Pages
https://icssw.org/en/meshcom/
