T4

T4 V1.3 ILI9341 LCD Display

1 total reviews

$21.15

Sale Sold out

Quantity

About Shipping

Methods & Delivery Time

Please note that all delivery times are estimated for reference only.

Check More Info: Shipping Policy

We only charge you for the cost of the product and shipping, no taxes are included.

MCU	ESP32
Flash	4MB
PSRAM	8MB
Wireless Connectivity	Wi-fi 802.11 b/g/n, BL V4.2+BLE
Programming Platform	Arduino-ide, Micropython
Serial chip	CH9102F QFN24
Display Optional	2. 2
Onboard functions	Buttons: Boot+RST battery power detection
ILI9341 TFT LCD	Resolution 320x240
support 65K color display	4-wire SPI interface
Working Power Supply	3.3V
Driver IC	ILI9341
Support arduino library TFT_ espl	Support USB/LI-PO Battery
JST Connect type	JST GH 1. 25mm

If you need technical support please check below link to find more details.

Who can use
It's easier to master these development boards with a basic programming knowledge [engineers/ students/ makers, etc..]
